The DR® ATV Disc Harrow is designed for breaking up soil clods after plowing and preparing a smoother surface for planting. It can also be used to chop up weeds and old crop residue and to uproot weeds in sandy soils.

Designed for use with ATVs, UTVs, and garden tractors, the disc harrow features ten offset notched steel discs, a powder-coated tubular steel frame, pneumatic tires, adjustable cutting depth, and a turnbuckle pitch adjustment.

Product Note: Globe Martio is an independent retailer. This product is manufactured by DR® Power Equipment and is not a Globe Martio-manufactured product. DR® and other manufacturer names, trademarks, and product technologies belong to their respective owners.

Soil Preparation and Weed Control

The DR® Disc Harrow is designed to break up clods of soil following plowing, helping create a smoother surface for planting game food plots, cover crops, or large vegetable gardens.

The discs can also be used to chop up weeds and old crop residue. According to the manufacturer, the harrow can be particularly effective for uprooting and destroying weeds in sandy soils.

Ten Offset Notched Discs

The disc harrow uses ten 14-inch notched steel discs arranged in an offset configuration. The discs are designed to cut into and break up soil as the harrow is pulled across the work area.

The cutting depth can be adjusted to as much as 4 inches, allowing the operator to set the working depth according to the soil and application.

33-Inch Working Width

The unit measures 36 inches wide overall and provides a 33-inch working width. This compact configuration is designed for use behind ATVs, UTVs, and garden tractors.

Pneumatic Tires

The DR® Disc Harrow is equipped with 13-inch pneumatic tires designed to roll easily during transport and operation.

Tubular Steel Frame

The frame is constructed from rugged 2-inch x 2-inch tubular steel and features a powder-coated finish. The frame provides the structure supporting the disc assembly, hitch, and adjustment components.

Adjustable Cutting Depth and Pitch

The disc harrow provides adjustable cutting depth up to 4 inches. A turnbuckle is used for pitch adjustment, allowing the working angle of the disc assembly to be adjusted for different soil conditions and applications.

Ball Hitch

A 2-inch ball hitch allows the disc harrow to be connected to most compatible ATVs, UTVs, or garden tractors.

Users should verify that their towing vehicle and hitch configuration are compatible with the implement before operation.

Product Specifications

• Product Type: ATV Disc Harrow
• Overall Width: 36 inches
• Working Width: 33 inches
• Discs: 10 offset notched steel discs
• Disc Diameter: 14 inches
• Tires: 13-inch pneumatic
• Frame: 2-inch x 2-inch tubular steel
• Frame Finish: Powder-coated
• Maximum Cutting Depth: Up to 4 inches
• Hitch: 2-inch ball hitch
• Compatible Vehicles: ATVs, UTVs, and garden tractors
• Pitch Adjustment: Turnbuckle
• Weight: 287 lbs.
• Manufacturer: DR® Power Equipment

Manufacturer Warranty Information

• Warranty: 2 years residential; 90 days commercial

Warranty coverage is provided by the manufacturer and may be subject to the manufacturer’s applicable warranty terms and conditions.

Available through Globe Martio, the DR® ATV Disc Harrow provides a compact 33-inch working width for soil preparation, clod breaking, and weed or crop-residue management behind compatible ATVs, UTVs, and garden tractors.
